Welded Razor Mesh Ribbon Fencing 1.2m x 2.5m

Minimum Order Quantity : 500 liner meter Price : 16.66$ per liner meter
Packaging Details : All metal Pallets Delivery Time : 7 work days
Payment Terms : TT30% deposit balance 70% at sight of finished products Supply Ability : 10000 liner meters
Place of Origin: Europea Design China Made Brand Name: Razor Welde Wire Mesh
Certification: ISO Model Number: 75mmx150mm

Detail Information

Materials: Carbon Steel Or Stainless Steel Blade Length: Blade Length: 22/30/60mm
Square: 50X50mm,100x100mm, 50X100mm Etc Rhombus Hole: 50X100mm/75X150m/150X300mm
Height: 1.2/1.5/1.8/2.1/2.4m Width: 2.5m / 3.0m / 6.0m Etc

Product Description

welded razor wire flat wrap coil /Welded Flat Razor Wire Mesh/Concertina Coil Wire/Welded Razor Mesh (high quality)


Welded razor wire mesh is a multi-functional, high security mesh fencing made of straight-blade netting welded together,packaging into a roll form for transport. Welded Razor Wire Mesh is used in operations to pave the field after the installation of a blade barrier. This product can protect you and your property, and ensures the safety of the protective barriers.

This welded razor wire mesh security fence product is almost impossible to climb or cut off with the standard tools,also it has a neat appearance.
welded ripper razor wire mesh


 welded ripper razor wire mesh







































The benefits of welded razor wire mesh :
It is almost impossible to climb.
High-strength steel core very difficult to cut off.
Powerful security fence barriers neat appearance.
No secondary use, so he will not be stolen.
Extremely simple to install, needs three to four to install molding.

Welded razor wire mesh (or Welded razor fence or Diamond razor mesh)
is a straight razor barbed wire , welded mesh processed,which can be welded into a diamond, rectangular hole (aperture can be produced according to customers’ requirements),nice,and the card cannot climb down, blocking strong deterrent force strong. It can be integrated with other fence and can also be used alone.

This kind of razor wire is extremely easy to install, Features of welded razor wire mesh:
1. Non-climbing;
2. Robust welded structure;
3. Zinc coating improve corrosive resistance;
4. Available in square and diamond profile.

This Welded Razor Wire Mesh security fence product is almost impossible to climb or cut off with the standard tools,
also it has a neat appearance.

Welded razor wire mesh Hole Type:
1. Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.
2. Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.
welded ripper razor wire mesh

Gauge diameter
Hole shape
Mesh width
Suited blade specifications
100mm×100mm
Square hole,diamond
1.2m ~ 2.4m
BTO-10.12.18.22.28.30, CBT-60.65
100mm×150mm
Square hole,diamond
1.2m ~ 2.4m
BTO-10.12.18.22.28.30, CBT-60.65
100mm×200mm
Square hole,diamond
1.2m ~ 2.4m
BTO-10.12.18.22.28.30, CBT-60.65
150mm×300mm
Square hole,diamond
1.2m ~ 2.4m
BTO-10.12.18.22.28.30, CBT-60.65
(other nets hole can according to customers' special needs)

There are standard specifications of welded razor wire fence.
Razor type: CBT-60, BTO-22, BTO-30.
Hole: Diamond,square,rectangle; such as diamond hole 15x30 cm ; 7.5x15 cm; square hole 20x20 cm; rectangle hole 15x30 cm
Height: 0.5 - 2.4 m
Length: 1-50 m
Raw material: High quality stainless steel wire and sheet, and high quality low carbon steel wire and sheet.
Core wire: 2.5 mm.
Sheet thickness: 0.5 mm.
Custom specifications are available at your specific requirement.





welded ripper razor wire mesh





of Rede Laminada
Type
Razor Mesh(Diamond Hole)
Razor Mesh(Square Hole)
Thickness of Sheet
0.5mm±0.05mm
Wire Diameter
2.5mm±0.1mm
Height
1.0m-2.4m
Length
2.0m-10.0m
Mesh Size
75mmx150mm
100mmx200mm
150mmx300mm
150mmx150mm
200mmx200mm
300mmx300mm
Special Specification can be produced according to your request


Razor mesh fence is a versatile, high security mesh fence designed to protect you and your property without marring the appearance of the property,extremely difficult to cut,hard to climb.

1. Panel Height
1.0 - 2.4 m (1.2 /1.8 /2.1 /2.4)

2. Panel Length
2.0 - 10.0 m

3. Hole Shape
Square or Diamond

4.Hole Size /Mesh Size
Square Hole Size: 100 * 100 mm, 150 * 150 mm, 200 * 200 mm
Diamond Hole Size: 75 * 150 mm, 100 * 200 mm, 150 * 300 mm

Below are our standard specifications of welded razor mesh:
Mesh Size
Mesh Shape
Panel Width
Available Blade Style
100mm x 100mm
Square / Diamond
1.2m – 2.4m
BTO-10, 12, 18, 22, 28, 30, CBT-60, 65
100mm x 150mm
Square / Diamond
1.2m – 2.4m
BTO-10, 12, 18, 22, 28, 30, CBT-60, 65
100mm x 200mm
Square / Diamond
1.2m – 2.4m
BTO-10, 12, 18, 22, 28, 30, CBT-60, 65
150mm x 300mm
Square / Diamond
1.2m – 2.4m
BTO-10, 12, 18, 22, 28, 30, CBT-60, 65


Welded Razor Wire Fence Mesh is a multi-functional,high security mesh fencing made of straight-blade netting welded together,packaging into a roll form for transport.Razor wire mesh is used in operations to pave the field after the installation of a blade barrier.This product can protect you and your property, and ensures the safety of the protective barriers.
This razor wire security fence product is almost impossible to climb or cut off with the standard tools, also it has a neat appearance.
.Welded Razor Wire mesh size
Diamond mesh size : 75x150mm, 100x200mm, 150x300mm
Oblique Square mesh size : 150mm, 200mm, 300mm
The rectangular mesh size: 100mmx150mm
The width and length could be produced as per the customers’ requirement



Packaging & Shipping
Usually the Supported piers attached concertina barrier plain welded anti climb razor wire fences yard guard barbed wire welded mesh fencing package is rolls,for panels are steel pallets packages.


FAQ

1: Shipment: 30days after receive your 30% T/T advance payment. Or L/C.
2: Payment: 30% T/T in advance, the balance by T/T against fax copy of B/L.
