Powder Coated Decorative Pyramid Fence Panel 1630mm height x 2500mm width RAL 6005 Powder Coated 50mm*200mm
Product Details:
| Place of Origin: | Europea Design China Made |
| Brand Name: | LNF-2d fencing panels |
| Certification: | ISO |
| Model Number: | 868 and 656 twin wire |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500 liner meter |
|---|---|
| Price: | 3.88$ per liner meter |
| Packaging Details: | All metal Pallets |
| Delivery Time: | 7 work days |
| Payment Terms: | TT30% deposit balance 70% at sight of finished products |
| Supply Ability: | 10000 liner meters |
|
Detail Information |
|||
| Materials: | Q235 Steel | Color: | RAL 6005 Or 9003 And So On |
|---|---|---|---|
| Treatment: | Hot Dipped Glavanized | Mesh Opening: | 50mm X 200mm ,55mm X 200mm |
| Diameter: | 656 ,868,565,545 Mm Etc | Type: | Weld |
| Warranty: | 5 -25 Years Depand On The Treatment | Main Market: | Europea ,Middle East ,USA ,AU Etc |
| Accessoires: | Clamp And Post Caps Etc | Customized: | Available |
| Feature: | Rigidity | Application: | Garden Fence, Farm Fence, Residential Fence, Highway Fence, Railway Fence, Balcony Fence, Airport Fence, Stadium Fence, Municipal Fence, Bridge Fence, Stair Fence, Air-Condition Fence, 868 Fence |
| Trade Mark: | N/M | Sample: | Free But Pay Freight Cost |
| Top Type: | Pyramid Decorative | ||
| High Light: | wire mesh fencing,chain wire fencing |
||
Product Description
Powder Coated Decorative Pyramid Fence Panel 1630mm height x 2500mm width RAL 6005 Powder Coated 50mm*200mm
Powder Coated Decorative Pyramid Fence Panel 1630mm height x 2500mm width RAL 6005 Powder Coated 50mm*200mm
Double wire fence is a flat panel, constructed from double horizontal wires and a vertical wire which can create a strong rigid fence when fitted to a RHS post or SHS post. General used in government place,factory land,School playgrounds,Public buildings,Car parks,Business parks and other places.
Panel-Type A (6-5-6)
| Mesh Size | Wire Thickness | Surface Treatment | Panel Width | Weight | Height |
|
50*200mm
55*200mm |
1*∅5mm Vertical wire & 2*∅6mm Horizontal wire | Galvanized and Electrostatic polyester powder coated | 2.50m |
9.00kg/11.50kg/ 14.20kg/16.80kg/ 19.30kg/21.90kg/ 24.60kg/27.10kg/ 29.20kg/31.70kg |
0.63m/0.83m/1.03m/ 1.23m/1.43m/1.63m/ 1.83m/2.03m/2.23m/2.43m |
Panel-Type B (8-6-8)
| Mesh Size | Wire Thickness | Surface Treatment | Panel Width | Weight | Height |
|
50*200mm
55*200mm
|
1*∅6mm Vertical wire & 2*∅8mm Horizontal wire | Galvanized and Electrostatic polyester powder coated | 2.50m |
14.60kg/18.80kg/23.00kg 27.10kg/31.30kg/35.40kg 39.50kg/43.70kg/48.00kg 52.00kg
|
0.63m/0.83m/1.03m/ 1.23m/1.43m/1.63m/ 1.83m/2.03m/2.23m/2.43m |
Post
| SHS tube | 60*60mm, 1.5-4mm |
| RHS tube | 60*40/80*40mm, 2.0-2.5mm |
| Peach post | 50*70/60*90/70*100mm,1.2mm or 1.5mm |
| Surface treatment | Galvanized and Electrostatic polyester powder coated |
| Length | On the basis of panel height |
| Base plate | Available |
| Rain hat | plastic or metal |
| Fittings | M8*40 safety bolt and 47*25mm steel clips are required |
Decorative Pyramid Fence Panel Specifications
Panel Height: 0.9-2m
Panel Width: 2-2.5m
Panel Opening: 50x200mm. 50*100 etc
Vertical Wire diameter: 6mm, Horizontal Wire diameter: 8mm*2
Fence Post: 60*60*2 mm
Profile mast height: 0.9 m-2m
Flange: 13 * 13*5 mm, 100*100*4mm, 120*120*5mm
Color Range: RAL6005, RAL6005, RAL9005, RAL9010, RAL5010, RAL7037, RAL1006. Another color can make as your interesting.
Packing: Panels in pallets with plastic film, post with plastic bags
Decorative Pyramid Fence Panel Application: Used in parks, residential place or another place
Key Features: Decorative Pyramid Fence Panel Unique and beautiful design, high-quality raw materials, high-adhesion of galvanised + electrostatic polyester coating technology makes the pyramid with a high anti-corrosion ability barrier.
At the same time, an increase of double-wire barrier of the high-intensity pyramid.
If you want to know more about Decorative pyramid fence panel, Please don't hesitate to email us.
Panel Height: 0.9-2m
Panel Width: 2-2.5m
Panel Opening: 50x200mm. 50*100 etc
Vertical Wire diameter: 6mm, Horizontal Wire diameter: 8mm*2
Fence Post: 60*60*2 mm
Profile mast height: 0.9 m-2m
Flange: 13 * 13*5 mm, 100*100*4mm, 120*120*5mm
Color Range: RAL6005, RAL6005, RAL9005, RAL9010, RAL5010, RAL7037, RAL1006. Another color can make as your interesting.
Packing: Panels in pallets with plastic film, post with plastic bags
Decorative Pyramid Fence Panel Application: Used in parks, residential place or another place
Key Features: Decorative Pyramid Fence Panel Unique and beautiful design, high-quality raw materials, high-adhesion of galvanised + electrostatic polyester coating technology makes the pyramid with a high anti-corrosion ability barrier.
At the same time, an increase of double-wire barrier of the high-intensity pyramid.
If you want to know more about Decorative pyramid fence panel, Please don't hesitate to email us.
| Fence Height(mm) | Panel Dimensions W*H(mm) |
Post Height | No.of Fixings |
| 900 | 2015*886 | 1100 | 2 |
| 1100 | 2015*1086 | 1300 | 2 |
| 1300 | 2015*1286 | 1500 | 3 |
| 1500 | 2015*1486 | 1700 | 3 |
Want to Know more details about this product
